QLC5257GXY1 type
Classification
QLC5257GXY1 type
Product Introduction
Technical Parameters
Chassis type: DFL1250A13
General length: 10890 mm
General width: 2500 mm
General height: 3900 mm
Wheel base: 5350 + 1350 mm
Front tread: 2040 mm
Rear tread: 1860 mm
Front overhang: 1460 mm
Maximum speed: 90 km/h
Maximum gradient: 30%
Oil consumption for 100km: 33 L
Minimum turning radius: 12 m
Unladen mass: 17400 kg
Rated loading quality: 7470 kg
Gross mass: 25000 kg
Effective volume of tank: 16.34 m³
Tank working pressure (Mpa): -0.049 - 0.0784, +0.2
Maximal tank uplifted angle (°): 45
Vacuum pump: -
Maximum vacuum degree (Mpa): -0.049 - 0.0784
Theoretics displacement (m³/min): 66 - 89
Air compressor: -
Displacement (m³/min): 10
Maximal pressure (Mpa): 0.196
Hydraulic system: Hyva (Imported from the Netherlands)
Nominal displacement (m³/min): 50
Rated working pressure (Mpa): 16
Control method: Manual air control
Sucking capacity (t/h): 25 - 50
Blowing capacity (t/h): 30 - 60
Remnant dust ratio (%): ≤0.4
All valves: Ebara / Luco
Wuhan Yunshengte Automobile Manufacturing Co., Ltd.
Contact Tel: 027 - 88866283/205
